CAT 5e- Cat 6- CAT 6 Cable Tutorial

So, when someone refers to 568A, are they talking about the standard, or the wiring scheme? The answer, is that it depends on the context. If they were to say "The entire office fully complies with 568A", obviously, they would be talking about the standard. If they were to say "The jacks and patch panels are all 568A", then they would be referring to the wiring scheme.

The 568 committee, with good intentions, decided to allow both wiring methods (568A & 568B) to exist within the 568A Standard. The reason was that at the time, a great deal of cabling plants had been installed to the B standard (formerly known as WECO or AT&T 258A). Even though they allowed both wiring methods, they stated in their standard that 568A wiring would be the preferred method for all new installations. Time, and popular opinion, went in the other direction. The most popular wiring method today is 568B. Having both A & B methods does nothing but cause errors and confusion. Originally, patch panels and jacks were manufactured either A or B. In most cases, they were not labeled as such. Most suppliers stocked only the B wired products. Luckily, today, almost all jacks and patch panels show diagrams for both A and B. The only difference between the two is the interchanging of the 2nd and 3rd pairs (white/orange and white/green, respectively).

So which method to choose? As we stated earlier; There is no difference, whatsoever, between the two wiring schemes, in connectivity or performance when connected form one modular device to another. The answer, is that it does not matter at all, unless you are terminating one end onto a punch block, in which case, the A method has an advantage. The main thing is that you choose one method, and stick with it. I recommend to all installers that they terminate one segment on both the jack and patch panel sides, and test for proper continuity. It has happened to many professionals, where they terminated the entire installation, and then discovered that the two ends were wired for different methods. Then they had to re-terminate all of the cables on one end completely to correct the situation.

The following charts should be very helpful in illustrating the difference between the A & B methods. For those who are not familiar with telephony, tip (T) refers to the positive (+) side, and ring (R) refers to the negative side of the circuit. The white/blue pair (the first pair in the cable) consists of two wires that are twisted together. They are the white/blue (tip) and the blue/white (ring). The white/blue wire is predominately white with a blue stripe. The blue/white is the inverse, predominately blue with a white stripe.

Category 5, 5 E, 6 and 7 Performance Specification Chart

Category 6 (CAT 6) technology is rapidly growing in the telecommunications industry’s commercial market. CAT 6 has been under development since late 1997. Originally, the wiring was intended to go from the 100 MHz capability of CAT 5 to 200 MHz, but later that was revised to 250 MHz. CAT 6 provides for other metrics as well, variables that become important at high bandwidth rates. These include crosstalk, or interference between wire pairs, and skew, the difference in timing of signals on the wires.
